Documentation Conventions¶

Exceptions Allowed¶

Unless otherwise stated in the project-specific CONTRIBUTIONS.md file, each project based on this specification shall develop documentation as defined by this annex.

Development Environment¶

Overview¶

In addition to the development tools needed to manage and submit any contribution within the Git environment (e.g., Git, GitHub), developing project documentation requires the following tools:

• A text editor, which is used to create and edit markdown and yaml files,
• Python, which is required to run MkDocs,
• MkDocs, which is an open-source tool for translating a set of markdown files into a static website, and
• Materials for MkDocs, which is an open-source tool that extends the markdown language to support additional features that are useful for developing the look and feel of the project's documentation.

This combination of tools has been selected because it:

• is designed to be easy to install and use,
• requires minimal setup,
• works well with Git and GitHub,
• supports search functionality,
• can produce a static website,
• when coupled with add-ons, can produce PDFs
• has an active development community

It is recommended to establish this development environment prior to making any edits. Generating the documentation website locally from a known baseline allows the contributor to verify that the development environment is working correctly prior to introducing edits to the files. Contributors are required to generate the documentation locally to verify that their proposed changes do not introduce any errors to the project. The MkDocs development environment allows users to see their changes in real time so that any errors can be addressed quickly.

Text Editor¶

Any text editor can be used to produce markdown and yaml files. These files are to have the extensions of ".md" and ".yml", respectively.

Contributors are encouraged to use Visual Studio Code, which is an open-source editor, with the following extensions enabled as it provides a reasonably close rendering of the final display format:

• Markdown Preview Enhanced by Yiyi Wang, this extension provides a markdown previewer with support for diagrams, math (LaTeX), mermaid, charts, and more;
• markdownlint by David Anson, this extension assists in ensuring markdown files follow consistent formatting rules; and
• YAML by Red Hat, this extension provides syntax highlighting, validation, and autocomplete for YAML files.

While any text editor can be used, this suite of tools offers a free solution that is designed to render the markdown in real-time while assisting the user in producing high quality code. However, users should be aware that the toolset still does not attempt to render some of the more advanced features of Materials for MkDocs. The final look and feel can be obtained using the MkDocs server.

Python¶

MkDocs requires Python 3.8 or higher. You can check to see if Python is already installed and its version with the following command:

python --version

The most recent version of Python can be installed from official Python website.

Once installed, you should verify by running both the python --version and pip --version commands. PIP should be installed as a part of the Python package.

MkDocs¶

Running the MkDocs server locally allows the contributor to see proposed changes in real-time and test them thoroughly prior to submitting pull requests. To install MkDocs, run

pip install mkdocs

Once installed, verify its installation with:

mkdocs --version

Once you have verified the installation, start the MkDocs server by changing to the directory containing your cloned copy of the project repository and running

mkdocs serve

Once the server is running, you can direct a web browser to localhost port 8000 to see the development version of the website. This site will be updated in realtime as you update files in the repository. If you want to create a static site, However, to render all elements within the project correctly, you will need to install Materials for MkDocs.

Materials for MkDocs¶

To install Materials for MkDocs and the commonly used extensions for ITS projects, run the following command:

pip install mkdocs-material pymdown-extensions

Working with the Content¶

The content of ITS open-source documentation is generally written in Markdown, a lightweight and easy-to-use markup language that allows you to format text in a readable and visually appealing way.

Please read the "Frequently Used Markdown" section for details about how to use it in this project.

Default Document Structure¶

ITS open-source projects can cover a range of projects that have wildly different documentation needs. Each project is allowed to define its own structure, but unless otherwise specified shall use the structure defined in this document, which is intended for projects that result in a product that can be conceptualized as a single traditional document (e.g., a traditional standard).

Each major portion of the document shall be defined in a separate markdown file. Major portions are defined as:

• the title page, which shall be index.md;
• each top-level section of the front matter (e.g., Foreword, Introduction);
• each section in the body of the document; and
• each annex.

The document structure shall be reflected in the project's mkdocs.yml file under the nav section with all front matter located under a Front Matter heading.

    - Front Matter:
      - Title Page: index.md
      - Notices: notices.md
      - Acknowledgements: acknowledgements.md
      - Foreword: foreword.md
      - Introduction: introduction.md
    - 1 General: general.md
    - 2 Overview: overview.md
    - 3 Commenter Responsibilities: commenter-responsibilities.md
    - 4 Contributor Responsibilities: contributor-responsibilities.md
    - 5 Maintainer Responsibilities: maintainer-responsibilities.md
    - 6 WG Responsibilities: wg-responsibilities.md
    - A Code of Conduct: code-of-conduct.md
    - B Documentation Conventions: documentation-conventions.md
    - C Coding Conventions: code-quality.md

Structure of the Title Page File¶

The index.md file shall represent the title page of the document and shall:

• Start with a line containing a hashtag and nothing else
• Include code that suppresses unwanted markdownlint warnings
• Identify the status of the document
• Define the Document Identifier (e.g., NTCIP X8008)
• Define the Document Title (e.g., ITS Open-Source Process)
• Any other information required by the Standards Development Organization (SDO)

#
<!-- markdownlint-disable MD033 -->
<div style="text-align: center; font-style: italic; font-weight: bold;">
  A proposal to the NTCIP Joint Committee</div>
<div style="text-align: center; font-size: 1.5em; font-weight: bold;">
  NTCIP X8008
</div>
---
<div style="text-align: center; font-size: 1.5em; font-weight: bold;">
  National Transportation Communications ITS Protocol
</div>
<div style="text-align: center; font-size: 2em; font-weight: bold;">
  ITS Open-Source Process
</div>
<!-- markdownlint-enable MD033 -->

Structure of All Other Front Matter Files¶

Each file representing a major portion of the front matter, other than the title page, shall include a single level 1 heading that has the same title as defined in the nav section of the mkdocs.yml file and is the first line of the document

# Foreword

Structure of a Section File¶

Each file representing a section of the main body of the document shall:

• Start with code that sets the section counter for the body to the section number while suppressing unwanted markdownlint warnings
• Include a single level 1 heading that has the same title as defined in the nav section of the mkdocs.yml file and occurs immediately after the code defining the section number
• End each heading with {.body}

<!-- markdownlint-enable require-heading-annex -->
<div markdown="1">
<style>
    :root { --section-number: 2; --section-style: decimal; }
</style>

Structure of an Annex File¶

Each file representing an annex of the document shall:

• Start with code that sets the section counter for the annex to the numerical order of the annex (the script will transform this into an alphabetic letter)
• Include a single level 1 heading that has the same title as defined in the nav section of the mkdocs.yml file and occurs immediately after the code defining the section number
• End each heading with {.annex}

<!-- markdownlint-enable require-heading-annex -->
<div markdown="1">
<style>
    :root { --section-number: 2; --section-style: upper-alpha; }
</style>

# Example Annex {.annex}

Adding Definitions to the Glossary¶

If you add definitions to the project's glossary, ensure the definitions are added alphabetically.

Frequently Used Markdown¶

Headings¶

The hash (#) symbol at the start of a line denotes a heading (e.g., section, clause, subclause). There are six levels of headings, and the number of hash symbols indicates the heading level. The title of the heading should appear after the hash symbols and a space.

### Heading 3

#### Heading 4

Text Formatting¶

• Make text bold by enclosing it with double asterisks (**).
• Make text italic by enclosing it with single underscores (_).
• Create inline code by wrapping text with backticks (`).

**This is a bold text.**

_This is an italic text._

This is an`inline code`.

Lists¶

• Create ordered lists using numbers followed by a period (1., 2., etc.).
• Create unordered lists using hyphens (-).
• The line before a list must be blank and a list cannot be immediately preceded by a different list
• The style for the list is defined by the first list item

1.  Item 1
2.  Item 2

New List

- Unordered Item 1
- Unordered Item 2

Links¶

Create links using square brackets ([]) for the link text and parentheses (()) for the URL.

[NTCIP](https://ntcip.org)

Images¶

Embed images using an exclamation mark (!), followed by square brackets ([]) for the alt text, and parentheses (()) for the image URL. AN optional attribute field can be added to the end to specify the size.

Example

![NTCIP](_assets/images/NTCIP.jpg){ width=200px }

Block quotations¶

Create a blockquote using the greater-than symbol (>) or through Materials for MkDocs' admonition quote (!!! quote).

> This is a blockquote.

!!! quote
    This is a Materials for MkDocs admonition quote.

Code Blocks¶

Create code blocks using triple backticks (```) for fenced code blocks and specify a language next to the backticks before the fenced code block to highlight the syntax.

bash git pull

``` bash
bash git pull

Admonitions¶

Create callout out blocks for different purposes using the Materials for MkDocs admonitions feature by including three explanation points and the admonition type with the contained text indented by four spaces (!!! note)

!!! note
    This is a note.

!!! tip
    This is a tip.

Materials for MkDocs supports the following standard admonitions:

• abstract
• bug
• danger
• example
• failure
• info
• note
• question
• quote
• success
• tip
• warning

Markdown Tips¶

• Preview your Markdown locally to ensure proper formatting before submitting your contribution.
• Keep your Markdown content organized, and use headings to structure your sections.
• There should be exactly one heading 1 within each file.
• Use code blocks to highlight code snippets or configuration examples.
• See the official Markdown Guide for more information about Markdown.
• See the Materials for MkDocs Guide for more information about Materials for MkDocs.
